Capabilities

t1

Everyday Volume Capability

  • Layers (1-14)
  • Lines and Spaces 3mil line / 3mil space
  • Panel Thickness <= 250 mils
  • Controlled Impedance +/- 10%
  • All types of final finishes available
  • Blind and Buried Vias
  • Heat Sink Technology
  • High Performance and Emerging Technology Materials
  • Sequential Lamination
  • Conductive and Non-Conductive Via Fill and Planerization
  • BGA
  • Ultra-Fine Pitch
  • Minimum core thickness: .003
  • Maximum layer count: 14
  • Minimum multi-layer thickness: .025″
  • Maximum multi-layer thickness (non-HASL): .015″
  • Maximum multi-layer thickness (HASL): .0170″
  • Blind/buried vias – sequential lamination
  • Design and Verification of impedance control
  • Pre-CAM DRC Analysis
  • CAM-controlled Panelization with DFM
  • Extracted Net-list Comparison
  • Lead free alternative High Tg laminates : – Example, Isola 370HR, 185HR, Iteq 180, Ventec VT47, Grace GA170
  • All Teflon (Rogers, Taconic, Arlon, Nelco)
  • Standard FR4, FR406, FR408, BT, Cyanate Esters
  • Polyimides
  • GETEK ⁄ Megtron ⁄ Nelco-13
  • Ceramic of various types
  • Inner layer maximum Cu weight : 4oz
  • Outer layer maximum Cu weight : 8oz
  • Minimum Cu weight : 1/4 oz

ETCHING

Minimum Conductor Width :

Start Cu Foil weight Internal External
0.5 oz. .003″ .004″
1.0 oz. .004″ .005″
2.0 oz. .005″ .006″
3.0+ oz. .006″ .007″

Minimum Feature Spacing :

Start Cu Foil weight Internal External
0.5 oz. .003″ .004″
1.0 oz. .005″ .006″
2.0 oz. .006″ .0075″
3.0+ oz. .007″ .009″
  • Max. Aspect Ratio: 10 to 1
  • Min. hole size tolerance (plated):+ .003″ Min hole size tolerance (unplated): +.0015″
  • Min. drilled hole size: 6 mil; maximum hole size: 250 mil
  • Min. annular plane clearance of drilled hole: .010″
  • Min. internal pad size to drill hole size: +.012″
  • Min. external pad size to drill hole size: +.010″
  • Dual Access Testing – Universal grid
  • Net list Testing (Gerber – extracted/IPC- D-356)
  • Fixtureless Testing for Proto/Small Volume
  • Impedance Testing (Polar CITS-500) Impedance Tolerance: + /- 5%
  • Min. Continuity Test: 10 Ohm
  • Max Isolation Test:10 M Ohm
  • Voltage: 10 – 100 VDC
  • Fine Pitch Testing:
  • Min. SMD Pitch (fixtureless): .012″
  • Min. BGA Pitch (fixture): 1 mm (.0394)
  • HASL – Hot Air Solder Level
  • Lead Free Hot Air Level
  • ENIG – Electroless Nickel / Immersion Gold
  • Electroless Palladium
  • Electrolytic Hard Gold over Electrolytic Nickel
  • Electrolytic Soft gold and Electrolytic Nickel
  • Immersion Tin
  • Immersion Silver
  • OSP – Organic Solderable Preservative/HT-Organic Solderable
  • Carbon ink – switch pads
  • Spray-coated Photo-imageable solder mask
  • Screened epoxy solder mask
  • Screened UV-curable via plugging
  • Peelable mask with stencil
  • Min. web thickness: .004
  • Min. solder mask clearance : .0025
  • Conductive
  • Non-Conductive
  • Edge milling
  • Hard-tool Pierce and /or Blank
  • Edge beveling
  • Minimum slot width:.020″
  • Min. inside radius (milled): .015″
  • Min. Distance of Plated Hole to internal Trace or Plane .0075″
  • Min. Distance of Non-Plated Hole to internal Trace or Plane: Internal: .0075″, External .006″
  • Standard finished Minimum Annular Ring is .001″, if not specified.
  • Min. Pad to Drill Hole Size: Internal .010″, External .008″
  • Min. Plane Clearance to Drill Hole: .020″
  • Min. Drilled Hole Size: .008″
