Why On Time Circuits Inc. ?
We have the unique ability to adjust to the ever changing demands in business today. Our flexibility is the key to increasing your profits by saving your company time and money in the manufacturing cycle. From prototype to production, the On Time Circuits Inc. team will supply a quality product on time. We wants to establish a long term relationship With our customers.
Our Technology
On Time Circuits Inc. provides intricate single material as well as hybrid (combination of materials) circuits on Teflon, Woven Teflon, Thermoset materials, Cyanate Ceramics, Polyimide, Getek, BT and Cyanate Esters, FR4, FR406 and FR408 materials. We have processing capability for very high volume, as well as specialized prototype.
Our Quality
We take pride in the work we do. Our program is dynamic with a focus on continuous improvement aimed at customer satisfaction. We are utilizing several tools including DOE and statistical analysis to assist us in our goals. We have Six Sigma Black Belts on our staff and have begun training our engineers as
Green Belts.
Welcome to
On Time Circuits Inc.
On Time Circuits Inc. understands your technical challenges. Whether you need quick prototypes, a cost effective solution for your flex, rigid-flex, mixed dielectrics or our metal clad PCB’s, we have the experience, the people and the technology to meet these challenges. We compete in time and must go beyond our current boundaries to provide competitive PCB’s and services outside what is considered normal service.
On Time Circuits Inc. prides itself in being a Total Solutions Provider and manufactures quality rigid, metal-backed and flex printed circuit boards on various types of substrates for a variety of applications. These products can go into high speed computing, high frequency telecommunication ranging from aerospace to deep space, defense, LEDs and other heat sink automotive electronics, and navigation devices – right from small test and prototype quantities to large volume production. We provide all of our technologies in a time critical environment.
OUR
SERVICES
Core Competence
- Advanced Technology PCB Solutions
- High Frequency & High Speed Solutions
- Advanced RF & Microwave Solutions
- Thermal Management Expertise
- High Performance Material Selection
- Advanced Digital & RF Engineering
- Quick turn Protos & Productions
Rigid PCB Capabilities Overview
- Up to 12-14 Layer Multilayer
- Lines / Spaces: 4/4 Mils
- Blind & Buried Vias
- Panel Thickness: .015 to.250”
- Smallest Drill Size: 6 Mils
- Via In Pad with Fill & Plate Options
- IPC Class 2 & 3 Compliant
Surface Finish Options
- Hot Air Solder Level (HASL)
- Lead Free Hot Air Level (LFHASL)
- Organic Surface Preservative (OSP)
- Electroless Nickel Immersion Gold
- Immersion Silver
- Immersion Tin
- Electrolytic Hard / Soft Gold
Enabling Technologies
- 12-14 Layer
- 4/4 Line & Space
- Edge Plating & Castellation
- Blind & Buried Vias
- 6 Mil Mechanical Drilling
- Sequential Lamination
- Controlled Impedance – With TDR
Enabling Technologies
- Selective Surface Finishes
- Back-drilling
- Positive Etch-back Boards
- Hybrid Multi-layers
- Teflon
- Heat Sink / Metal Core
- Blind & Buried Vias
Certifications
- ISO 9001:2015 Certified
- Fabrication to IPC Class 2 & 3
- ITAR Registered
- PPAP Repotting for Automotive Parts
- UL Certified File # E102394
- Minority Business Certified CH399
- Advanced Technology PCB Solutions
OUR
PROCESS
Service Differentiators
- Supply Chain Solutions
- Stocking Programs for Finished Goods
- Stocking Programs for Specialty Laminates
- Stocking Programs for Specialty Thermal Materials
- Seamless Manufacturing Model
- Low Cost Manufacturing Alliances & Capabilities
Competitive Advantages
- Technology Leadership
- Quick Turn File Analysis & Quotes
- Competitive Cost Structure
- Seamless Manufacturing Solution
- Customized Supply Chain Solutions
- Engineering Support
About Us
Welcome to On Time Circuits Inc., the ideal PCB manufacturer for today’s electronics industry. On Time Circuits Inc. has earned a solid reputation as a reliable source for printed circuit boards. Our goal is to provide PCBs for research and development as well as Proto type and production requirements for business today.
Services
- 45000 Square Feet Technology Center
- ISO 9001:2015 Certified
- IPC Class 2 & 3 Process, Electrical testing & Quality Compliance
- ITAR Registered & Compliant
- Certified Minority Business
- UL Certified File # E102394
- Quick Turn Capability
- Same Day Turns for FR-4 Double Sided Boards
- 24 Hours – 10 day for protos / low volume production
- 5-10 day metal Core (MCPCBs/IMPCBs)
- Standard Delivery
- 10 – 15 days for standard production
- 20 days advanced technologies
- 20 – 35 days metal backed PCBs
- Stocking programs available to reduce/minimize lead times
- Single Sided, Double-Sided & Multi- Layer PCB’s
- In-House Fabrication of Prototype, Medium & Volume Production
- Quick Turn Lead Times from 24 Hours
- Partners in Low Cost Regions
We take pride in the work we do. Our program is dynamic with a focus on continuous improvement aimed at customer satisfaction. We are utilizing several tools including DOE and statistical analysis to assist us in our goals. We have Six Sigma Black Belts on our staff and have begun training our engineers as Green Belts.
- Cyanate Ester & Polyimide (Isola/Ventec/Naniya)
- All Rogers & Duriod RF Microwave Materials
- 3000 / 4000 / 5000 / 6000 / series materials and CLET- XT / 4835 / 2929 Bondplys
- Taconic Microwave Materials
- High Speed Digital Materials
- Neltec Microwave Materials
- Arlon Materials
- Bergquist / Thermagon / MCPCB / ICPCB and Other LED Materials
